Nanotech SOL-GEL Coating
|
 |
|
|
Sol Gel Coating is an environmental friendly, non-toxicology, non-yellowing, excellent hard and heat stability ceramic coating. Owing to the Nano-scale effect (10~30 nm), the ceramic coating can just be cured at low temperature about 180~250°C. It can be taken as very thin glass or enamel. The Nano-structured surfaces contribute to the nonstick or stainless character, which was the well-known Lotus Effect.
|
|
 Advantages
|
-Excellent binding powder for inorganic substrate, such like glass, metal and ceramic etc.
-Excellent Heat Resistance -Nonstick and easy to clean up.
-Excellent in Weather Resistance -Easy to coat with low baking temperature.
-Excellent Hardness -Excellent in Chemical Resistance.
-Excellent antirust -Excellent insulating material.
|
|
Interior Top Coating Series
|
| Item |
Test Method |
Performance |
| Hardness |
Mitsubishi Uni Pencil |
4H~9H (depends on the hardness of substrate) |
| Adhesion(1.5mm x 1.5mm) |
Cross hatch |
100/100 no removal |
| Solvent resistance |
200 time with IPA and MEK |
No visual change |
| Acid resistance |
5% H2SO4 x 48 hours |
No blister, no visual change |
| Acid pollutants resistance |
A magic marker, vapor 24 hours remove with alcohol |
No visual change |
| Abrasion resistance |
2.5 kgf with 3M cleaning cloth |
> 500 cycles |
| Alkali resistance |
5% Na2CO3 x 48 hrs |
No blister, no visual change |
| Salt spray resistance |
5% NaCl x 3000 hours |
No blister. |
| Heat resistance |
600°C x 1 hour |
No crack, no visual change |
| Boiling water resistance |
Boiling water x 2hrs |
No visual change, no crack, no blister |
|
|
|
|
|
